Summary: W-TEL-OTC series outdoor telecommunication cabinet is mainly used in the field of traffic, CATV, electric power etc.Can be used under different conditions: gale, rain, snow, hail, frost, smog and solar radiate etc.The main part of the cabinet is made of magnesium and aluminum alloy. It can be last for 30 years of normal use. Specification: Cabinet materials: high-quality aluminum alloy and zinc sheet Adapts to frame design of "Sandwich" panel Temperature management, control system, power supply system, entrance guard, environment supervisory system and wiring unit module Cabinet meets the requirements of IP65 level of protection Double layer (with heat insulation layer inside) Weather resistant & anti-graffiti painting. RAL7035 power coated EMC protection Corrosion protection. Vandal proof design with 3 pointing locking system. Adopt special imported outdoor industrial air- Conditioner/heat-exchanger/TEC/Fan system for cooling control The perfect earthing system to protect it from thunder. The enshroud dustproof net is installed in the air circulation system to protect the entry of dust and insects. Special A4 size material box and unique PC panel, easy maintenance and operating. Operation of W-TEL outdoor telecom cabinet : Temperature :-45°to +55° Humidity : ≤90(30°) Atmospheric pressure :70-106Pa Protection : IP65 Type 1 < Air-con model > Air-con cabinet adopts the frames design of "Sandwich", The inner and outer cabinet are all made of high quality aluminum alloy ,zinc sheet covered with aluminum and zinc sheet covered with magnesium with good capability of preservation , which use 3-4 point security locking system from anti-theft safely .The thermal insulation materials en-chased in the component can prevent conductive heat like outdoor ultraviolet radiation from infiltrating into the cabinet , select professional air -con with the modulation of constant temperature and humidity and setting of heating to ensure the cabinet provided with the best operating environment . The inside is composed of standard 19inch rack frame , temperature management and control system , power supply system , entrance guard , environment supervisory system and wiring unit module etc .The cabinet meets the requirement of IP65 level of protection . Type 2 < Heat-exchanger model > Cabinet of heat-ex-changer model adopts the frame design of " Sandwich " panel . and the inner and outer cabinet are all made of high - quality alloy or stainless steel panel with good capacity of preservation . which introduce the 3 point latch-up structure to strengthen the safety of the cabinet . The thermal insulating insulating material en-chased in the component can prevent the conductive heat like outdoor ultraviolet radiation from infiltrating in the cabinet , select heat-ex-changer system with heater to ensure the environment inside of the cabinet meet the requirements of the normal movement of communications equipment , The inside is composed of standard 19-inch frame , temperature management and control system , power supply , door guard , environment monitoring system and wiring system etc .  The cabinet meets IP 65 protection level . Type 3 < Fan model > Fan model cabinet adopts to sandwich panel and both of the inner and outer are made of high quality aluminum alloy and stainless steel sheet with good capacity of preservation , which introduce the security 3 point locking system for anti-theft . Special thermal material can prevent the outdoor ultraviolet radiation from infiltrating into the cabinet effectively . select the glands trip of special material to ensure the long-term sealing performance of the cabinet , the fan and air out take equipment on the top guarantee timely and high efficient heat emission . Cabinet meets IP65 level . Cabinet protection : Projects :

Summary: Outdoor telecom integrated BTS mobile shelter solving program can be used in building top, mountain area, road, village and living blocks etc. It is easy to operate, time saving and can be used widely in different conditions which can save space and costs. It can provide protection under different working conditions and weather. Working Standard: fireproofing: dust-proof waterproof wind resistance: shockproof: antisepsis: the surface is made of sandwich-steel-panel ,meet the requirement of 500 hours thunder resistance Connection features: Door lock: IP 65 working life: more than 20 years Warm keeping features: the wall material is warm-keeping material polyurethane. heat transfer coefficient

Summary: W-TEL-OBC-series outdoor telecommunication battery cabinet is mainly used in the field of traffic, CATV, electric power etc.Can be used under different conditions: gale, rain, snow, hail, frost, smog and solar radiate etc.The main part of the cabinet is made of magnesium and aluminum alloy. It can be last for 30 years of normal use. Cabinet materials: high-quality aluminum alloy and zinc sheet Adapts to frame design of "Sandwich" panel Temperature management, control system, power supply system, entrance guard, environment supervisory system and wiring unit module Cabinet meets the requirements of IP65 level of protection Double layer (with heat insulation layer inside) Weather resistant & anti-graffiti painting. RAL7035 power coated EMC protection Corrosion protection. Vandal proof design with 3 pointing locking system. Adopt special imported outdoor industrial air- Conditioner/heat-exchanger/TEC/Fan system for cooling control The perfect earthing system to protect it from thunder. The enshroud dust-proof net is installed in the air circulation system to protect the entry of dust and insects. Special A4 size material box and unique PC panel, easy maintenance and operating. Operation of W-TEL outdoor telecom battery cabinet : Temperature :-45°to +55° Humidity : ≤90(30°) Atmospheric pressure :70-106Pa Protection : IP65 Battery cabinet with OEM design for different type of battery system . 1> Natural ventilation cooling system 2> Air-conditioner cooling system 3> Heat-exchanger cooling system 4> Fan cooling system 5> TEC cooling system Indoor battery cabinet Open rack battery cabinet Outdoor battery cabinet Solar system battery cabinet

Area of Applications: Can be used in outside plant, underground, aerial, pedestal and direct buried applications. The device allows for direct jointing and bifurcated jointing. It also protects fiber optic splices from the elements while providing fast and easy no-cost reentry. Specifications: Excellent capability to withstand quake, pressure, stretch. It is Strong and durable. Excellent capability to adapt to natural conditions. It can operate smoothly in temperatures varying. From -40 +80: . Sealing performance: the innovative and unique waterproof elastic sealing is easy to install and seal completely. The splice case and sealing packing can be opened and reused for more than 10 times, ensure excellent performance and meet all the requirements for telecommunications. Service life: 25 years in service for all major components in the splice case. Technical features: Circle numbers of totality Max. 436 core Cable number of max.8-out and 8-in Totality loss: ≤0.03dB Anti-bump capacity 16N m three times no leak & no rip Max.voltage 15KV DC Atmospheric pressure defense level EN60529 IP54 IP58 Fire-resistance level UL94 VO 70Kpa-106Kpa Performance condition: temperature :-40 ~ +80 Relative humidity: ≤0-85% Dome type (Cap type) Cassette type Splitter type Accessories

Fiber patch panel system 1.Each port of this Cat.6 FTP patch panel has the same unaided cabling structure ,it will make sure that the performance of each port consistent. 2.The cable management and grounding device are combined in this patch panel. All kind of cables with different dimensions can be fixed on the patch panel. The shielding foil of the cables and the grounding device of the patch panel can be connected very well so that the shielding effect of this patch panel will be very outstanding. 3.According to the standard of ISO/IEC 11801:2002 CLASS E and ANSI/TIA/EIA/568-B.2-1 Cat6 Standard ,the T568A and T568B color cord are printed both on the PCB and IDC surface to give a correct guide when a engineer punch the cables. Fitting foe horizontal distribution in the equipments room and equipments connecting. 4.Connecting: RJ45 port for Cat6 FTP patch cord and IDC for horizontal distribution cables 5.Environmentalist requirement; in accord with the ROHS requirement. 6.Compatibility: compatible for all kinds of Cat6.Cat5e and Cat5 system. 7.Entire steel outer frame, with plastic powder cladding(non-electric part) and zincification cladding (shielding parts) 8.RJ45 jack: PBT frame with 50u golden phosphor bronze pins; shielding shell of the RJ45jack: brass housing with nickel-plated. IDC clip: Tinned phosphor bronze pins. 9.Testing conduction of transmitting capability: 250MHz Patch Panel catalog

W-TEL-PDC Electric Power Distribution cabinet is used to distribution electric power both indoor and outdoor of telecommunication cabinet. The surface material is spray coating plastics, which is anti-rust and antisepsis. High –quality of air switch is used inside the cabinet, which can ensure good air and heat exchanging. This can be mounted directly on walls. Product Features: The OEM design cabinet is made of cold rolled steel and the surface material is spray coating plastics, contour Artistic. Integration electric power distribution panel optional types: thunder resistance or no thunder resistance.

Usage: Suitable for installing and placing the 19” standard equipment and the equipment of metric and ETIS standards. OEM design from 2U 4U 6U 8U 12U 15U 18U 22U 24U 26U 28U 32U 36U 42U 48U 52U in capacity. Main features: Complete types and specifications. Customized cabinets are also available upon request. Modular design for all parts to meet your any configuration needs. Wiring holes reserved on both the upper and the lower covers for free cabling. Sufficient cabling space inside the cabinet with routes designed on all sides. L Side panel detachable and special components for cabinet combining. Safe and reliable grounding protection. The bottom, top, air blow, air ejection and heat ejection can be chosen to raise the reliability of the equipment; Firm structure with the maximum static load of 1200kg ； Pedestals, sole angles and bottom wheels can be chosen to secure the machine cabinet; Front and back doors, light and right doors, copings and sole plate are convenient for disassembly and assembly; Degrease, acid wash, antisepticised with phosphor, water washing ,imported plastic powder coating with plastic static spraying. Design characteristics: ·The appearance design is luxurious and handsome, fully in accordance with the 19" Standard and ETSI Standard followed by international inter-net products; ·It wholly uses high-quality SPCC cold rolling steel plate with the thickness of 1.2-2.0mm and the maximum static load of 800kg; ·The whole case is welded strongly. The strong shell of the case can ensure the safe operation of the system in any environment; ·The visual area of the front door is large so that it is convenient for observing equipment; ·The meshes of high density of the front door sealing strip are fit for ventilation and heat emission of the equipment; ·Beautiful and decent after static electricity plastic spraying,colors can be chosen by the customers.; ·The whole machine is dealt with through phosphate antisepsis plastic spraying. Floor standing type W-TEL-NWC- wall mounted small type cabinet has many advantages such as small size ,compact ,space saving etc. mainly used to contain network equipment and small servers etc. And we can design according to customer’s requests. It is widely used in computer data network, controlling and so on. Wall mount type Projects for Michigan network data center

Summary: Wide Band Access cabinet is designed for living blocks, can install Ethernet exchanger, optical splice tray, light and power transmitter, power module, CAT5 wiring connection module and audio module. Specification: Can install optical fiber transmitter and optical pigtails, connect earth net Can install ADSL equipment and wiring connection fix device, used to Connect ADSL has the wiring fix device for network equipment, wire holder and Transmitter has protecting plug of audio cable distribution and electric power connection thunder resistance anti-theft device Technical specification: Power: multi-plug Fan start temperature: thunder resistance Working conditions: -10-55 working temperature: -10-55 Humidity 5 90 Non-condensing

Feature: Corrosion-proof alloy aluminum or SMC or ABS base and cover. The cover and base feature superior anti-rust performance, suitable for harsh outdoor condition. The cabinet is either pole mounted or wall mounted.IDC and wire wrap modules are available. Suitable for the connection between branch line and the communication line in the city, county and countryside. The type of wall inlaid indoor branch box was suitable for the connection between indoor communication cables and the user lines. (1)Outdoor type：The body of the case is made of aluminum alloy castings, with spray-painted face, elegant and anti-corrosion; the reasonable structure of right-opened case-cover and reversible block leading to better airproof and easy opening or operation. There is pressive button for fixing cable indoor, in order to prevent from dropping of cable lug when forcing; it is better airproof for using rubber sealing loop between the body and the cover; reversible block leading to easy opening or operation; the fixing method as special design can save installation time and to lighten labor intensity of pole in field; add the space of the case properly, that can insure the good sealing of bottom case cover when fully loaded. (2)Indoor type: attractive appearance, borderline smooth, reversible block leading to easy opening or operation. Technical Indexes ·Suitable for the connection between branch line and the communication line in the city, county and countryside. ·The body of the case is made of aluminum alloy castings, smooth and stable. ·The reasonable structure of right-opened case-cover and reversible block leading to better airproof and easy opening or operation. ·pressive button for fixing cable indoor, in order to prevent from dropping of cable lug when forcing. ·the fixing method as special design can save installation time and to lighten labor intensity  of pole in field ·add the space of the case properly, that can insure the good sealing of bottom case cover when fully loaded. Main Technical Indexes: ·Environmental temperature ：－25℃～+40℃ ·Relative humidity：<95% ·Contact resistance between the lead and the end：≤5×10-3Ω ·Voltage-resistance strength：non-puncture, no arc-over 500VAC/1min Instruction Manual Environment Condition: Environment temperature: －55℃～+55℃    Environment temperature: －25℃～+55℃ Relative humidity: ≤95%                   Relative humidity: ≤95% Atmospheric pressure:70～160kp            Atmospheric pressure:70～160kp Electrical Performance Contact resistance: <5×10-3Ω Voltage-resistance:﹥ 5×103MΩ Voltage resistance strength：non-puncture, no are-over under 500Vac/30s Installation Method pole-hanged installation Fixing the hoop on the electrical pole with M12 bolt, and then let the branch cable clip. Wall-mounted installation Outdoor distribution box Ambient Temperature:-55x+55 Relative Humidity:≤95%(+30 ) Pressure: 70kPax106kPa. Indoor distribution box Ambient Temperature:-25x+40 Relative Humidity:≤95%(+30) Pressure:70kPax106kPa

Cable Splice Closure (Cable Connector - Cap Way) Protective equipment of cable connector used for the connection of cable and the cable ramification of programmed control line series. The switch box of line can be replaced. Cable Splice Closure (Cable Connector - Cap Way) Cable Splice Closure: Characteristics of the product: The plastic for engineering of high resistance, the anti-aging and the material of stainless steel to the external pieces. Impermeability, waterproof, anti-gas, protection to the corrosion. Easy operation, high economic value, respective use. Protection to the corrosion, long life of the use; acceleration of construction, easy for the emergency repair; saving of reduction, maintenance equipments of expenses. Specification: 10 pairs - 30 pairs, 50 pairs, 100 pairs, 200 pairs. Cable Splice Closure: Technical characteristics: Inflation 200Kpa, stays 100h in condition of normal atmosphere, value of the loss of pension<5 Inflation 60Kpa, during a circulation of the change of the temperature (- 30℃~+60℃), value of the loss of pension<5 Cable Splice Closure (Horizontal Connector of Cable-Way) Protective equipment of cable connector used for the connection of cable and the cable ramification of programmed control line series. The switch box of line can be replaced Cable Splice Closure: Characteristics of the product: Application the plastic for engineering of high resistance, the anti-aging and the material of stainless steel to the external pieces. Impermeability, waterproof, anti-gas, protection to the corrosion. easy operation, high economic value, respective use. Protection to the corrosion, long life of the use; acceleration of construction, easy for the emergency repair; saving of reduction, maintenance equipments of expenses. Can use in covered and aerial form. Specification: 10 pairs - 30 pairs, 50 pairs, 100 pairs, 200 pairs. Cable Splice Closure: Technical characteristics: Inflation 200Kpa, stays 100h in condition of normal atmosphere, value of the loss of pressure<5; Inflation 60Kpa, during a circulation of the change of the temperature (- 30℃~+60℃), value of the loss of Pressure<5; Cable Splice Closure: Conditions of the work: temperatura-30℃~+60℃ Humidity relati≤95% pressure Atmosphere 70Kpa~106Kpa

Description: W-TEL-CCA series large capacity cabinet has the functions of fiber distribution, splice, storage and dispatch. It has dogged performance of resisting the open -air environment and can resist severe climatic changes and serious working environment. The protection grade reaches IP65. The cabinet is made of SMC material / Stainless steel for your option . Meanwhile, it can be used in the XPON connection to install optical fiber splitter, to compose a integration system of connection, distribution and light source distribution. This matches the large capacity XPON connection greatly.We are working for all kinds of fiber optic cross connection cabinet :48cores,96cores,144core ,288 core ,576 core etc . Product characteristics: Made of SMC material or stainless steel, good heat insulation, seal belt inside the door make it work efficiently in different conditions.. Mould operation of cable fuse and distribution, easy maintenance Direct fusion applicable Apply of bundle, belt-shaped and non-belt-shaped optical cables FC, SC, ST, LC adapter can be installed in it. Reliable optical fiber protection, earthing etc. The adapter is 30 °angle to the surface makes it easy to operate and protect the operator from the burning hurt. Different fusion and wiring marks, easy operation and making notes. Reasonable optical fiber cable panel to ensure the Dia of cable is more than 40mm in all directions. Can install different types of optical fiber splitter to compose a compact cable distribution system Features: 1.Excellent performance such as: water-proof,damp-proof,anti-erosion,anti-strike. Able to withstand abrupt climate change and extreme environment 2.Capacity can be flexibly customized as required 3.Installation is quick and convenient 4.Built-in direct splice unit is capable for providing direct connection function. 5.Perfect design of fiber wiring routing could facilitate management and maintenance of fibers 6.With secure and reliable fastening and grounding protection devices for the optic fiber 7.Applicable to strap-shaped and non-strap shaped fibers 8.Unique patent for the design of the door key,can never be easily broken. 9.With unique design of the adjust structure of temperature. Main Technical Parameters: (1)Operating temperature: between -40°C and +60°C (2)RH(relative humidity):95%(at temperature:+40°C) (3)Atmospheric pressure: between 70kpa and 106kpa (4)Isolation resistance: ≥2X10000M/500V(DC) (5)Anti-voltage strength: ≥3000V(DC)1min,no breakdown (6)Strong heat-proof performance,because the cabinet is made from high strength unsaturated polyester glass fiber reinforcement material called SMC (7)Static load-bearing capacity: 980N for the cover,980N for side surface,200N for door hinge (8)Sealing performance: YD/T988-199 (9)Using 12 core ODF panel integrated unit Models introduction: MODEL SIZE CAPACITY ASSEBLING TYPE REMARKS W-CCA48 450×315×185 48cores outdoor wall-mounted suitable for adapters such as FC,SC,length of pigtail can be 2m single-end,patch cable can be optional:2m~3m W-CCA96 960×525×325 96cores outdoor floor type W-CCA144 9600×525×325 144cores outdoor floor type W-CCA288 1450×750×325 288cores outdoor floor type W-CCA576 1450×750×620 576cores outdoor floor type SMC material type Stainless steel material type

1.Application Modular ODF is used in center office, optical cross connection point and network access point in fiber access network projects to realize the fiber fusion, fiber optic cable distribution, management and protection. The unit is installed in the optical distribution frame, and can be flexibly Confederate. it is the necessary equipment in the optical access network. 2.Summary It is convenient for the connection and distribution of fiber optic cable and also good at distribution in the large capacity exchange bureau, CATV fiber system and fiber optic communication system. W-TEL optical distribution frame (ODF) is specifically designed for the first sector of FTTX operating; it is normally placed at service provider's central office (CO). The optical distribution frame brings a stable solution for safely containing FDU (Fiber Distribution Unit) modules. The frame adopts enclosed type structure to protect the optical fibers from dust. 3.Feature 1. 19" Standard rack mount 2. Material: SPCC cold rolled steel 3. Designed by full mobilization: A. Unit body have the fusion of optical fiber fusion, tray storing and distribution B. the integrated fusion and distribution tray can be singly taken out to meet the demands for operation. 4. Optical cable, pigtail fiber and patch cords can be clearly managed, 5. Easy for installation of inlay,convenient to expand capacity,obliquity of adapter is 30 degree. 6. Ensure the bend radius of patch cord and avoid laser burning eyes. 7. FC, SC port is available for the integrated fusion and distribution tray 8. Two sides accommodate cable entry and exit 4.Specification 1. Under the general air pressure, 500VDC,insulation resistance≥1000MΩ; 2. The high voltage protection can undertake 3000VDC,no spark-through and flashover within 1 minutes. 3. Technical and quality grade reaches the ISO/IEC11801 requirement. 4. Working temperature-20°C~+55°C; 5. Working humidity≤95% (30°C); 6. Working atmospheric pressure 70~106KPa 5.Product list Capacity Dimension(mm) Weight(kg) 12 port 430 x 300 x 35 3KG 24 port 430 x 300 x 70 5KG 48 port 430 x 300 x 140 7KG 72 port 430 x 300 x 200 10KG 96 port 430 x 300 x 250 15kg 6.Testing parameter Availability Performance temperature: -40 ~+60 Relative humidity ≤95 +40 Atmospheric pressure 70kPa~106kPa Performance wavelength 850nm 1310nm 1550nm Loss(insertion interchange and repetition) ≤0.3dB Turn loss PC type≥45dB UPCtype≥50dB APC type≥60dB Insertion and pull life 1000times Max. voltage 3000VDC/1min Insulated resistance 2x104M /500VDC 6.General description Material SPCC, Aluminum Alloys and etc. anti-corrosion material Thickness 0.8mm, 1.0mm, 1.2mm, 1.5mm, 2.0mm and etc are all available Processing Laser cutting, CNC punching, CNC bending, welding, stamping, etc Surface treatment Painting, hot galvanized, powder coating, polishing, brushing, catastrophes, etc Certification ISO9001:2001 Deliver time 15-20 days after deposit received Files available Solid works, Auto CAD, PDF Brand W-TEL IP IP65&66 Main customers China Uni com, China Telecom, CMCC etc. Application fields Used for FTTZ, FTTB, FTTR, and wireless base station Structure OEM design Insulation Resistance >1000MV/500VDC Withstand Voltage >3000VDC/min and no breakdown fly arc Package Package with hard paper box, Plywood box, wooden box, Contract Manufacturing OEM Service, Design Service, Buyer Label Offered Installation Method Complete module installation Capacity 1,200, 4,000, 5,000 and 6000 lines Corrosion resistant performance All the materials selected are with high corrosion resistance performance
