Model XTHZ-10 Driving Mode Servo motor labeling methods The bottle is stand into, stand labeling, stand out Conveyor Speed（m/min） ≤50 Labeling Accuracy ±1.0mm Label material Adhesive sticker, opaque or transparent label The inner diameter of label roll 76 mm The outer diameter of label roll 350 mm(max) The size of bottle Can customized The size of label Height 20-180 mm  length 25-200 mm Printer to use air 5kg/cm ² Voltage AC220V 50/60HZ Single side (Can customized as buyer need)

Model PLM-S Driving Mode Servo motor Yield（pcs/min） 10-80(depends on product and label size) Operating direction Left or Right Conveyor Speed（m/min） ≤40 Labeling Accuracy ±1.0 mm The inner diameter of label roll 76 mm The outer diameter of label roll 350 mm(max) The suitable size of label Width 15-150 mm  length 15-300 mm The suitable size of labeling objects Can customized Printer use air 5kg/cm ² Voltage (In China) AC220V 50/60HZ Single phase (Can customized as client need) Power（w） 850W Weight（kg） 360 Machine size 2300（L） 800 (W)  1500 (H) mm

Model XTHZ-10 Driving Mode Servo motor labeling methods The bottle is stand into, stand labeling, stand out Conveyor Speed（m/min） ≤40 Labeling Accuracy ±1.0mm Label material Adhesive sticker, opaque or transparent label The inner diameter of label roll 76 mm The outer diameter of label roll 350 mm(max) The size of bottle Outer diameter 20-100mm, height 25-200mm The size of label Height 20-180 mm  length 25-200 mm Printer to use air 5kg/cm ² Voltage AC220V 50/60HZ Single side (Can customized as buyer need)

Model SLM-A Driving Mode Servo motor Operating direction Left or Right Conveyor Speed（m/min） ≤40 Labeling Accuracy ±1.0 mm The inner diameter of label roll 76 mm The outer diameter of label roll 350 mm(max) The suitable size of label Width 15-300 mm  length 15-300 mm The suitable size of labeling objects Can customized depends on client product Voltage (In China) AC220V 50/60HZ Single phase (Can customized as client need)

Model DPM-SLM-A Driving Mode Servo motor Yield（pcs/min） 20-130 Operating direction Left or Right Conveyor Speed（m/min） ≤40 Labeling Accuracy ±1.0 mm Label material Adhesive sticker, opaque or transparent label The inner diameter of label roll 76 mm The outer diameter of label roll 350 mm(max) The suitable size of label Width 15-160 mm  length 15-300 mm The suitable size of labeling objects Can customized Printer use air 5kg/cm ² Voltage (In China) AC220V 50/60HZ Single phase (Can customized as client need)

Model PWM-ALS104 Driving Mode Avery 104 Yield（pcs/min） 30-220 Operating direction Left or Right Conveyor Speed（m/min） ≤40 Labeling Accuracy ±1.0 mm The inner diameter of label roll 76 mm The outer diameter of label roll 350 mm(max) The suitable size of label Width 15-100 mm  length 15-80 mm The suitable size of labeling objects Customized depends on client product Printer use air 5kg/cm ² Power（w） 600W Weight（kg） 200 Machine size 1800（L） 800 (W)  1300 (H) mm

MIC 18-18-1 It is applicable for equal pressure filler and capper of carbonated drinks in beer and drink industry. Adopt products: beer , craft beer , gas water, carbonated water, co2 water, etc liquid like carbonated drinks. Machine working principle: 1. Isobaric filling system, controled by pressure, accuracy is +/-1%，liquid level difference is not more than 4-5mm. cause bottle itself has different when produced. (requires steady pressure and temperature at 0-4degree). 2. Bottle capping machine is qualified for Chinese capping standard, and no air leakage at all. 3. About beer oxygen content, we have device for foaming after fill and remove oxygen of beer, and nitrogen filling for replace air too. 3. Aluminum cap and crown cap are ok problem working on our capping machine(different capping head), We use our own technical drawing and own processing machine, to make sure our capping head quality and always easy to purchase. 4. If bottle stock on conveyor sensor will inform PLC to stop at the feeding part. 5. About machine automation, we are able to do what client required. 6. About machine test and shipment, we are stick with real production test till all problem is fix and then ship out. 7. Consider of product various ability, we are able to make machine for replace air from the can package. For this production line you might be interested in: 1> Carton packing machine 2> Pallet winding machine 3> Sticker labeling machine 4> Wet glue labeling macchine 5> Liquid level detective machine 6> Metal element detective machine 7> CIP cleaning system Related machines are: can filling seaming machine, can seaming machine, rotated oil can filling machine, rotated oil filling machine, beer filling machine, beer seaming machine, beer bottling machine and beer filler. DGF18-18-1 triple machine washing, filling in one, is on the base of introducing, digesting and absorbing foreign advanced technology. It is mainly used for soft drinks, juice, beer and other beverages without gas washing bottle, filling and capping. Its structure is advanced, stable, reliable, safe operation, convenient maintenance, the use of frequency conversion speed control, high production efficiency, is the ideal equipment for small and medium sized beverage factory. The production process of the machine are as follows: conveyor chain and triple a machine directly connected, bottles by conveyor chain through a screw into bottle shifting wheel by shifting the bottle star wheel transfer to three synthetic filling machine, into the filling machine of the bottle by retaining the bottom of the bottle holder. The whole machine equipment adopts a closed window, and the sealing window height is higher than the highest point of the equipment, and there is a proper passage in the bottle. →We sold one to The Republic of Yemen on MAY 31,2017.

Model SLM-A Driving Mode Servo motor Operating direction Left or Right Conveyor Speed（m/min） ≤40 Labeling Accuracy ±1.0 mm The inner diameter of label roll 76 mm The outer diameter of label roll 350 mm(max) The suitable size of label Width 15-300 mm  length 15-300 mm The suitable size of labeling objects Can customized depends on client product Voltage (In China) AC220V 50/60HZ Single phase (Can customized as client need)

MIC 18-6 It is applicable for equal pressure filler and capper of carbonated drinks in beer and drink industry. Adopt products: beer , craft beer , gas water, carbonated water, co2 water, etc liquid like carbonated drinks. Machine working principle: 1. Isobaric filling system, controled by pressure, accuracy is +/-1%，liquid level difference is not more than 2mm. (requires steady pressure and temperature at 0-4degree). 2. Can seaming machine is qualified for Chinese seaming standard, and no air leakage at all. 3. About beer oxygen content, we have device for foaming after fill and remove oxygen of beer, and nitrogen filling for replace air too. 3. Aluminum can and metal can are ok problem working on our seaming machine, We use our own technical drawing and own processing machine, to make sure our seaming head quality and always easy to purchase. 4. If bottle stock on conveyor sensor will inform PLC to stop at the feeding part. 5. About machine automation, we are able to do what client required. 6. About machine test and shipment, we are stick with real production test till all problem is fix and then ship out. 7. Consider of product various ability, we are able to make machine for replace air from the can package. For this production line you might be interested in: 1> Carton packing machine 2> Pallet winding machine 3> Sticker labeling machine 4> Liquid level detective machine 5> Metal element detective machine Related machines are: can filling seaming machine, can seaming machine, rotated oil can filling machine, rotated oil filling machine, beer filling machine, beer seaming machine, beer bottling machine and beer filler. Recent export news: (click for check news) We sold one to The Republic of Angola on April 25,2017.

This machine was designed for automatic can feeding, weighing, filling and failed packs detect & delete. It’s suitable for packaging powdery & grainy product, such as: milk powder, spice,herb glutamate, solid beverage, white sugar, dextrose, fodder, coffee power, solid medicament, powdery & grainy additive, dyestuff, etc. Main Characters: 1. The application of GMP 2. PLC Touch-screen and HMI : set the parameter , easy to control. 4. Servo auger screw : servo motor auger screw measure 5. Unique design to hold the bottle upper when filling , so not dust 6. Sensor control , no bottle no filling

Model DPM-SLM-A Driving Mode Servo motor Yield（pcs/min） 20-100 Operating direction Left or Right Conveyor Speed（m/min） ≤40 Labeling Accuracy ±1.0 mm Label material Adhesive sticker, opaque or transparent label The inner diameter of label roll 76 mm The outer diameter of label roll 350 mm(max) The suitable size of label Width 15-300 mm  length 15-300 mm The suitable size of labeling objects Can customized Printer use air 5kg/cm ² Voltage (In China) AC220V 50/60HZ Single phase (Can customized as client need)

SR series Non-PVC soft bag IV-solution production line is the highest efficiency product line, which is compiling all the most advanced technique. Used for the automatic filling of 50~5000ml conventional infusion, special infusion, flushing/urination, parenteral nutrients ， antibiotic and special medicine. Advantage: 1. For patent design, The production line becomes bag making ， filling and sealing integrated machine its length is compressed 1/3, the area of workshop and air-conditioner purify are decreased 1/3, so it can decrease the investment cost and use cost in furthest. 2. Because taking off the bag cross-connecting procedure, the reliability of production line can be raised more. Main Characteristic • Applying the advanced technology, it has reasonable structure and stable, reliable feature. •The filling system adopts mass flowmeter to metering, high precision and wide range for filling quantity, and can realize CIP/SIP. • It has high arranges. The servo system, PLC, pneumatic elements and so on, are complete select and use international brand, assure to run in steady and reliable. Technical parameter: TYPE SRD1A / 1200 SRD2A/2500 SRD4A / 5000 SRS6A /7500 SRDI2A / 15000 Main Parameters 1200 bags/h 2500bags/h 5000 bags/h 7500 bags/h 15000 bags/h Capacity 100ml,250ml,500ml Q'ty/ cycle 1 2 4 6 12 InterfaceMethods Boat interface Double tube interface Power Source 3 Phases 380V 50Hz Power 8KW 22KW 30KW 30KW 30KW Process
