Characteristic Suitable for quantitative weighing candy, melon seeds, potato chips, pistachios, peanuts, nuts, fruit, jelly, frozen dumpling, biscuits, candied fruit, camphor, raisins, almonds, chocolate, nuts, grains, pet food, puffed food, hardware parts, plastic parts and other granular, sheet, strip, irregular shape materials.

Characteristic 1.Double hopper weight alone separated from bags, with high working speed. 2.Feeder is adjustable with the proportion of materials to achieve high accuracy and high speed 3.Weight cell alone : steadily working, high sensitivity, instead of metering control system. 4.Present packing times can be saved, easily tracking the certified rate of products. 5.Touch screen in English with easy to operate 6.Calibration matched poise is used to delete the moving weight 7.Weighing hopper is covered by glass, less pollution to workshop. 8.Perfect-structured machine, easy to clear the remnant. And hanging weigher canbe disassembled for clearing.

Characteristic 1.Using new-style producing & control system , together with high precision and high speed related weighing & control instruments , which has the advantage of multi-function , high stability and expansibility .completely adapt to the highly continuous and repeated industrial manufacture. 2.Hauing the function of over-dosing restraining ,wrap self-correcting and over-weight warning. 3.The machine is a set of highly electro-mechanical integrated device. Computer control system and imported high-precision weighing sensors are adopted . All the parts which directly contact with products are made of 304 stainless steel. 4.Bag grip device is changeable for fitting different bag size. 5.Chemical grand belt coveyor or PVC flight conveyor optional 6.Industrial bag sealing or seaming device optional

Model KZ-250 KZ-320 KZ-350 Film width 250mm 320mm 350mm Bag length 45～ 280mm 120-280mm 150-330mm Bag width 30 ～ 110mm 50 ～ 160mm 50 ～ 160mm Packaging speed 40 ～ 300 bags/min 40 ～ 300 bags/min 40 ～ 300 bags/min Power supply 220V,50/60HZ,2.4Kw 220V,50/60HZ,2.4Kw 220V,50/60HZ,2.4Kw Dimension (mm) (L)3770×(W)670×(H)1450mm (L)3770×(W)670×(H)1450mm (L)3770×(W)670×(H)1450mm Weight 800Kg 800Kg 800Kg Model KZ-600 KZ-680 Film width 600mm 680mm Bag length 120 ～ 450mm 120-450mm Bag width 50 ～ 200mm 50 ～ 260mm Packaging speed 40 ～ 150 bags/min 40 ～ 100 bags/min Power supply 220V,50/60HZ,2.4Kw 220V,50/60HZ,2.4Kw Dimension (mm) (L)3770×(W)670×(H)1450mm (L)3770×(W)670×(H)1450mm Weight 800Kg 800Kg

Overview: This device consists of a bag automatic packaging machines and liquid filling machine supporting body butter is made. Mainly applies to: detergents, yellow sprinkles, soy sauce, vinegar, juice, beverage, pot bottom material, ketchup, peanut butter, jam, chili sauce, bean paste and other materials, automatic weighing and packing. Main features: 1.bags wide adaptation: For single PE, PE composite material, CPP composite materials, aluminum foil and other materials made of prefabricated multilayer composite film bags. 2. Packing materials loss low: This machine is used the preformed bag, the bag pattern is perfect, good sealing quality, resulting in improved product quality. 3.quick-change bag size: robotic device quick and easy adjustment.

Overview: Mainly by its sets of equipment to the bag packing machine with screw scales, screw feeder, supporting special cleaner made for pesticides, veterinary drugs, milk powder, dextrose, coffee powder, spices, additives and other powder materials, automatic feeding can automatically take bag, play yards, open bags, quantitative measurement, cleaning, filling, sealing, output of finished packaging machine. Main features: 1.bags wide adaptation: For single PE, PE composite material, CPP composite materials, aluminum foil and other materials made of prefabricated multilayer composite film bags. 2. Packing materials loss low: This machine is used the preformed bag, the bag pattern is perfect, good sealing quality, resulting in improved product quality. 3.quick-change bag size: robotic device quick and easy adjustment.

Overview: This device consists of a bag automatic packaging machines, intelligent combination weighing machine, the bucket elevator, working platform supporting made, mainly applicable to a variety of solid, granular, massive and materials weighed. Such as puffed food, snack foods, nuts, seeds, almonds, pistachios, pine nuts, candy, jelly, beans, food, frozen food, pet food, all kinds, hardware materials and other materials like automatic feeding, automatic take bag, playing yards, open bags, quantitative filling, pumping nitrogen sealing, product delivery.

Tank finishing Empty tank sterilization Mixing Vibration screwing feeding Automatic positioning quantitative feeding Tank sealing

Characteristic Automatic measure , filling, sealing, labeling, code...etc.Automatic production line Applicable bottle material : PET, glass bottles, tin, etc. Applicable product: milk powder, solid drink, coffee powder, protein powder, chemical powder, etc According to the specific request , Made for the customer.

Tank finishing Weigher Automatic Position Filling Machine Check Weigher Automatic capping machine ( Screw capping ) Automatic labeling machine

Characteristic Applied to various kinds of granules product .automatic measure , filling, sealing, labeling, code...etc.Automatic production line Applicable bottle material : PET, glass bottles, tin, etc. Applicable Product: all kinds of nuts, grain, candied fruit, canned fruit, etc. According to the specific request , Made for the customer.

Sealing type 3 side sealing Pillow bag sealing Measure method 0-100ml 0-100 ml Packing speed 40 -80 bag/min 25-60 bag/min Making bag size W:30-120 mm L:30-170 mm W:30-150 mm L: 30-170mm Packaging material Paper/PE, PET/AL, Foil/PE Nylon/PE, Tea-leaf filtering paper, etc. Paper/PE, PET/AL, Foil/PE Nylon/PE, Tea-leaf filtering paper, etc. Total power 1400W 1400W Power supply 380V or 220V 380V or 220V Weight 200KG 200KG Overall dimensions 625*750*1560 mm 625*750*1560 mm
