Catalogue Download Feature • Precision locator for terminal positions. • 1.2 metric tones pressure with minimal hand effort. • Interchangeable die set. • Crimp MC3* with optional die set. Parameters Model LY-2546B Capacity MC4： 2.5，4，6mm2 Length 215 mm Weight 0.5 kg

Catalogue Download Feature • Square crimping type. • Ergonomically designed handles and Ratchet control. • Precise crimping die sets and integral lock with self-releasing machanism ensure high-quality crimping effect after crimping repeatedly. • Accurate adjustment before ex works delivery. • Light and compact structure keep crimping effect. Parameters Model PZ 0.5-16 Terminal Type Cord End Sleeve and Wire Ferrules Crimping Capacity 0.5-16 mm² / 22-6AWG Length 220mm Weight 0.25kg Application Our cable crimper mainly used for electrical working, State Grid construction, underground cable construction, Building construction etc.

Catalogue Download Feature • Indent crimping • Easy to set by screwing adjustment for terminal size • One stroke of the handle complete the crimp • Critical parts fully heat treated Parameters Model KH-120 Terminal Type Tubular Cable Lugs and Connector Crimping Capacity 10-120mm²/#7-250MCM Size 560*120*30 mm Weight 2.8 kg Application Our cable crimper mainly used for electrical working, State Grid construction, underground cable construction, Building construction etc.

Catalogue Download Feature • Hexagon crimping • Dies could be OEM as per your country lugs sizes. • Revolving dies • Dies are made of SCM-40 hardest tool steel. Keep for long time. • Designed with accurate hole diameter and reliable terminations • No dies for replace, simply rotate die to required crimp size • Body are chrome plated. • Tools packed with inner box Parameters Model HX-50B Terminal Type Non-insulated connectors and cable lugs Crimping Capacity 6.0-50mm²/#10-1/0 Size 390*130*45 mm Weight 1.3kg Application Our cable crimper mainly used for electrical working, State Grid construction, underground cable construction, Building construction etc.

Catalogue Download

Catalogue Download Feature • Hexagon crimping type • Ergonomically designed handles and Ratchet control • Different handle color for your choice: one is single color, another is double color • Reduce 50% energy when crimping. • Precise crimping die sets and integral lock with self-releasing machanism ensure high-quality crimping effect after crimping repeatedly. • Light and compact structure keep crimping effect. Parameters Model LXC8 6-6/6-6R Terminal Type Cord End Sleeve and Wire Ferrules Crimping Capacity 0.25-6 mm² / 24-10AWG Length 175mm Weight 0.38kg Application Our cable crimper mainly used for electrical working, State Grid construction, underground cable construction, Building construction etc.

Catalogue Download Feature • Square crimping type • Ergonomically designed handles and Ratchet control • Different handle color for your choice: one is single color, another is double color • Reduce 50% energy when crimping. • Precise crimping die sets and integral lock with self-releasing machanism ensure high-quality crimping effect after crimping repeatedly. • Accurate adjustment before ex works delivery. • Light and compact structure keep crimping effect. Parameters Model LXC8 6-4/6-4R Terminal Type Cord End Sleeve and Wire Ferrules Crimping Capacity 0.25-6 mm² / 24-10AWG Length 175mm Weight 0.38kg Application Our cable crimper mainly used for electrical working, State Grid construction, underground cable construction, Building construction etc.

Catalogue Download Feature • Ergonomically designed handles and Ratchet control. • Reduce 50% energy when crimping. • Precise crimping die sets and integral lock with self-releasing machanism ensure high-quality crimping effect after crimping repeatedly. • Accurate adjustment before ex works delivery. • Light and compact structure keep crimping effect. Parameters Model SN-28B Terminal Type Non-insulated Receptacle and Tab Crimping Capacity 0.25-1.0 mm²/ 23-17AWG Length 190mm Weight 0.35kg Application Our cable crimper mainly used for electrical working, State Grid construction, underground cable construction, Building construction etc.

Catalogue Download Feature • There is more than 40 dies could be chosen, And we accept OEM dies • Following format don’t include the terminals, Please check the ternimal type with our dies drawing. • Reduce 50% energy when crimping. • Precise crimping die sets And integral lock with self-releasing machanism ensure high-quality crimping effect after crimping repeatedly. • Accurate adjustment before ex works delivery. • Light And compact structure keep crimping effect. Parameters No. Model no. Terminals Type Crimping CSNacity Size(mm)/Weight(kg) 1 SN-02C Insulated Terminals And Connector 0.25mm²_2.5mm² 24AWG-14AWG 190/0.35 2 SN-0725 Insulated Terminals And Connector 0.5-mm²_2.5mm² 20-14AWG 190/0.35 3. SN-02 Non-Insulated terminals And Connector 0.25mm²_2.5mm² 24AWG-14AWG 190/0.35 4 SN-0325 Non- Insulated Terminals 0.5-mm²_2.5mm² 20-13AWG 190/0.35 5 SN-06 Non Insulated Terminals 0.5-6mm²/20-10AWG 190/0.35 6 SN-02WF Cable end sleeve 0.14-2.5mm² /26-14AWG 190/0.35 7 SN-06WF Cable end sleeve 0.25-6mm² / 30-10AWG 190/0.35 8 SN-16WF Cable end sleeve 6-16mm² / 10-5AWG 190/0.35 9 SN-02WF2C Insulated Terminals And Connector 0.25-2.5mm² / 22-14AWG 0.5-2.5mm² / 20-14AWG 190/0.35 10 SN-28B Uninsulated receptacles And Tab2.8,4.8mm width terminals 0.1-1.0mm² / 28-18AWG 190/0.35 11 SN-48B Uninsulated receptacles And Tab 4.8mm width terminals 0.14-1.5mm² / 26-16AWG 190/0.35 12 SN-11011 Uninsulated receptacles And Tab 6.3mm width terminals 0.5-2.5mm²/24-14AWG 190/0.35 13 SN-03H Crimping Coaxial Cable 4.5mm² /3.25mm² 3.84mm²  /1.72mm² / 1.0mm² 190/0.35 14 SN-01BM D-Sub connector 0.08-5mm² / 28-20AWG 190/0.35 15 SN-28FL Tab 90°flag terminals 2.8mm² /14AWG 190/0.35 16 SN-05B Terminals 0.5mm²_1.5mm² 22AWG-16AWG 190/0.35 Application Our cable crimper mainly used for electrical working, State Grid construction, underground cable construction, Building construction etc.

Catalogue Download Feature • There is more than 40 dies could be chosen, And we accept OEM dies • Following format don’t include the terminals, Please check the ternimal type with our dies drawing. • Ergonomically designed TPR handles And Ratchet control • Reduce 50% energy when crimping. • Precise crimping die sets And integral lock with self-releasing machanism ensure high-quality crimping effect after crimping repeatedly. • Accurate adjustment before ex works delivery. • Light And compact structure keep crimping effect. Parameters No. Model No. Terminals Type Crimping Capacity Size(mm)/Weight(kg) 1 LY-30J Insulated Terminals LYd Connector 0.5-1.5mm2/20-16AWG 2.5mm2 / 14AWG 4-6mm2 / 12-10AWG 230/0.6 2 LY-03C Insulated Terminals LYd Connector 0.5-1.5mm2/20-16AWG 2.5mm2 / 14AWG 4-6mm2 / 12-10AWG 230/0.6 3. LY-18C Insulated terminals LYd Connector 10-16mm2 / 8-6AWG 230/0.6 4 LY-10 Non Insulated Terminals 1.5-6mm2 /17-10AWG 230/0.6 5 LY-101 Non Insulated Terminals 1.0-10mm2 /17-10AWG 230/0.6 6 LY-336N Non Insulated Terminals 1.5-10mm2 /20-8AWG 230/0.6 7 LY-04WFL Cord End Sleeve LYd Wire Ferrules 0.5-6mm2 / 20-16AWG 230/0.6 8 LY-06WF Cord End Sleeve LYd Wire Ferrules 0.5-6mm2 / 20-16AWG 230/0.6 9 LY-16WF Cord End Sleeve LYd Wire Ferrules 6-16mm2 / 10-5AWG 230/0.6 10 LY-25WF Cord End Sleeve LYd Wire Ferrules 6-25mm2 / 10-3AWG 230/0.6 11 LY-35WF Cord End Sleeve LYd Wire Ferrules 10-35mm2 / 8-2AWG 230/0.6 12 LY-26TW Cord End Sleeve LYd Wire Ferrules 2*0.5-6mm2/2*20-10AWG 230/0.6 13 LY-06WF2C Cord End Sleeve LYd Insulated terminals 0.5-6mm2 /0.5-2.5mm2 20-10AWG/20-14AWG 230/0.6 14 LY-03B Non-insulated Receptacles LYd Tab 0.5-6mm2 / 20-10AWG 230/0.6 15 LY-103 Wire Joint 0.5-6mm2 /20-10AWG 230/0.6 16 LY-0506FL Insulated 90°Flag Terminals 4.8mm2 /6.3mm2 3AWG/6AWG 230/0.6 17 LY-07FL Insulated 90°Flag Terminals 0.5-1.25mm2 /1.5-2.5mm2 20-18AWG /16-14AWG 230/0.6 18 LY-02H Coaxial cable 6.5mm/5.4mm/1.72mm RG59/62 230/0.6 19 LY-05H Coaxial cable 8.1/6.5/5.4/2.6/1.72mm RG58/59/62 230/0.6 20 LY-336C Coaxial cable 1.73/5.41/8.10mm RG58/59/62/6 230/0.6 21 LY-336J Coaxial cable 1.07/1.72/1.98/3.25/3.84/4.52MM RG174,179,Fiber Optic 230/0.6 22 LY-457 Coaxial cable 11/8.2/5.4MM RG58/6 230/0.6 23 LY-157 Airlines of Truned contact plugs 0.5-6 mm2/20-10AWG 230/0.6 24 LY-158 Airlines of Truned contact plugs 2.5-4-6mm2/13-10AWG 230/0.6 25 LY-1060A Open nose Terminals 10A-60A 230/0.6 26 LY-0510A Open nose Terminals 5A-10A 230/0.6 Application Our cable crimper mainly used for electrical working, State Grid construction, underground cable construction, Building construction etc.

Catalogue Download Feature • There is more than 40 dies could be chosen, And we accept OEM dies • Following format don’t include the terminals, Please check the ternimal type with our dies drawing. • Reduce 50% energy when crimping. • Precise crimping die sets And integral lock with self-releasing machanism ensure high-quality crimping effect after crimping repeatedly. • Accurate adjustment before ex works delivery. • Light And compact structure keep crimping effect. Parameters No. Model No. Terminals Type Crimping Capacity Size(mm)/Weight(kg) 1 LX-30J Insulated Terminals And Connector 0.5-1.5mm2/20-16AWG 2.5mm2 / 14AWG 4-6mm2 / 12-10AWG 230/0.6 2 LX-03C Insulated Terminals And Connector 0.5-1.5mm2/20-16AWG 2.5mm2 / 14AWG 4-6mm2 / 12-10AWG 230/0.6 3. LX-18C Insulated terminals And Connector 10-16mm2 / 8-6AWG 230/0.6 4 LX-10 Non Insulated Terminals 1.5-6mm2 /17-10AWG 230/0.6 5 LX-101 Non Insulated Terminals 1.0-10mm2 /17-10AWG 230/0.6 6 LX-336N Non Insulated Terminals 1.5-10mm2 /20-8AWG 230/0.6 7 LX-04WFL Cord End Sleeve And Wire Ferrules 0.5-6mm2 / 20-16AWG 230/0.6 8 LX-06WF Cord End Sleeve And Wire Ferrules 0.5-6mm2 / 20-16AWG 230/0.6 9 LX-16WF Cord End Sleeve And Wire Ferrules 6-16mm2 / 10-5AWG 230/0.6 10 LX-25WF Cord End Sleeve And Wire Ferrules 6-25mm2 / 10-3AWG 230/0.6 11 LX-35WF Cord End Sleeve And Wire Ferrules 10-35mm2 / 8-2AWG 230/0.6 12 LX-26TW Cord End Sleeve And Wire Ferrules 2*0.5-6mm2/2*20-10AWG 230/0.6 13 LX-06WF2C Cord End Sleeve And Insulated terminals 0.5-6mm2 /0.5-2.5mm2 20-10AWG/20-14AWG 230/0.6 14 LX-03B Non-insulated Receptacles And Tab 0.5-6mm2 / 20-10AWG 230/0.6 15 LX-103 Wire Joint 0.5-6mm2 /20-10AWG 230/0.6 16 LX-0506FL Insulated 90°Flag Terminals 4.8mm2 /6.3mm2 3AWG/6AWG 230/0.6 17 LX-07FL Insulated 90°Flag Terminals 0.5-1.25mm2 /1.5-2.5mm2 20-18AWG /16-14AWG 230/0.6 18 LX-02H Coaxial cable 6.5mm/5.4mm/1.72mm RG59/62 230/0.6 19 LX-05H Coaxial cable 8.1/6.5/5.4/2.6/1.72mm RG58/59/62 230/0.6 20 LX-336C Coaxial cable 1.73/5.41/8.10mm RG58/59/62/6 230/0.6 21 LX-336J Coaxial cable 1.07/1.72/1.98/3.25/3.84/4.52MM RG174,179,Fiber Optic 230/0.6 22 LX-457 Coaxial cable 11/8.2/5.4MM RG58/6 230/0.6 23 LX-157 Airlines of Truned contact plugs 0.5-6 mm2/20-10AWG 230/0.6 24 LX-158 Airlines of Truned contact plugs 2.5-4-6mm2/13-10AWG 230/0.6 25 LX-1060A Open nose Terminals 10A-60A 230/0.6 26 LX-0510A Open nose Terminals 5A-10A 230/0.6 Application Our cable crimper mainly used for electrical working, State Grid construction, underground cable construction, Building construction etc.

Catalogue Download Feature • There is more than 40 dies could be chosen, And we accept OEM dies • Following format don’t include the terminals, Please check the ternimal type with our dies drawing. • Ergonomically designed TPR handles And Ratchet control • Reduce 50% energy when crimping. • Precise crimping die sets And integral lock with self-releasing machanism ensure high-quality crimping effect after crimping repeatedly. • Accurate adjustment before ex works delivery. • Light And compact structure keep crimping effect. Parameters No. Model No. Terminals Type Crimping Capacity Size(mm)/Weight(kg) 1 AP-30J Insulated Terminals And Connector 0.5-1.5mm2/20-16AWG 2.5mm2 / 14AWG 4-6mm2 / 12-10AWG 245/0.64 2 AP-03C Insulated Terminals And Connector 0.5-1.5mm2/20-16AWG 2.5mm2 / 14AWG 4-6mm2 / 12-10AWG 245/0.64 3. AP-18C Insulated terminals And Connector 10-16mm2 / 8-6AWG 245/0.64 4 AP-10 Non Insulated Terminals 1.5-6mm2 /17-10AWG 245/0.64 5 AP-101 Non Insulated Terminals 1.0-10mm2 /17-10AWG 245/0.64 6 AP-336N Non Insulated Terminals 1.5-10mm2 /20-8AWG 245/0.64 7 AP-04WFL Cord End Sleeve And Wire Ferrules 0.5-6mm2 / 20-16AWG 245/0.64 8 AP-06WF Cord End Sleeve And Wire Ferrules 0.5-6mm2 / 20-16AWG 245/0.64 9 AP-16WF Cord End Sleeve And Wire Ferrules 6-16mm2 / 10-5AWG 245/0.64 10 AP-25WF Cord End Sleeve And Wire Ferrules 6-25mm2 / 10-3AWG 245/0.64 11 AP-35WF Cord End Sleeve And Wire Ferrules 10-35mm2 / 8-2AWG 245/0.64 12 AP-26TW Cord End Sleeve And Wire Ferrules 2*0.5-6mm2/2*20-10AWG 245/0.64 13 AP-06WF2C Cord End Sleeve And Insulated terminals 0.5-6mm2 /0.5-2.5mm2 20-10AWG/20-14AWG 245/0.64 14 AP-03B Non-insulated Receptacles And Tab 0.5-6mm2 / 20-10AWG 245/0.64 15 AP-103 Wire Joint 0.5-6mm2 /20-10AWG 245/0.64 16 AP-0506FL Insulated 90°Flag Terminals 4.8mm2 /6.3mm2 3AWG/6AWG 245/0.64 17 AP-07FL Insulated 90°Flag Terminals 0.5-1.25mm2 /1.5-2.5mm2 20-18AWG /16-14AWG 245/0.64 18 AP-02H Coaxial cable 6.5mm/5.4mm/1.72mm RG59/62 245/0.64 19 AP-05H Coaxial cable 8.1/6.5/5.4/2.6/1.72mm RG58/59/62 245/0.64 20 AP-336C Coaxial cable 1.73/5.41/8.10mm RG58/59/62/6 245/0.64 21 AP-336J Coaxial cable 1.07/1.72/1.98/3.25/3.84/4.52MM RG174,179,Fiber Optic 245/0.64 22 AP-457 Coaxial cable 11/8.2/5.4MM RG58/6 245/0.64 23 AP-157 Airlines of Truned contact plugs 0.5-6 mm2/20-10AWG 245/0.64 24 AP-158 Airlines of Truned contact plugs 2.5-4-6mm2/13-10AWG 245/0.64 25 AN-1060A Open nose Terminals 10A-60A 245/0.64 26 AN-0510A Open nose Terminals 5A-10A 245/0.64 Application Our cable crimper mainly used for electrical working, State Grid construction, underground cable construction, Building construction etc.
